EN10296 Minimum Q235 Carbon Steel
Plate Sheet JIS 1500mm Polished Steel Sheet Panels
SA516 Gr70N NACE Steel Plate Baffle ASME SA516-70 Boiler Steel
Plate 30MM,Common grade:Container plate: A516Gr60, A516Gr70,
Q345R,16MnR,Q370R, 16MnDR, 15CrMoR, A572Gr60, A573Gr70, 13MnNiMoR,
15CrMoR,12MnNiVR, 07MnNiMoR, 09MnNiDRLow-alloy plate: Q345B/C/D/E,
Q390A/B/C/D, Q420A/B/C,High-strength plate: Q460C/D, JG590, Q550D,
Q690D, SM490A-L,Ship plate: AH32, AH36, DH32, DH36, EH32,
EH36,Bridge steel: Q235QC, Q345QC, Q345QD, Q370QD, Q235GJD,
Q345GJB, Q345GJC, Q345GJD.
Product Details
| Width | 1000-3000mm (1000-2200mm usually used) | Standard | GB,ASTM,AISI,BS,JIS,DIN,EN |
| Surface | Clean, finishing,blasting and painting according to customer
requirement | Length | 1000-12000mm or as your request |
| Quality | MTC will be provided with goods, third part inspection is
acceptable, such as BV,SGS. | Certificate | API,ISO,SGS,BV,CE etc |
| Package | Standard export seaworthy package,suit for all kinds of transport,
or as required. | Trade term | Ex-Work,FOB,CNF,CFR,CIF,etc |
1. Supplementary Technology:
Hot rolled, controlled rolling, normalizing, annealed tempering.
Normalizing+ tempering, hardening + tempering.
HIC, SSC, SPWHT, third Party Test.
2. Size:
Thickness : 8mm-150mm
Width : 1000mm-4000mm
Length : 1000mm-20000mm
3. Chemical Composition:
| Steel Grade | Number | C | Si | Mn | Pmax | Smax | Altotal | N | Cr | Cub | Mo | | 16Mo3 | 1.5415 | 0.12 to 0.20 | ≤0.35 | 0.40to0.90 | 0.025 | 0.01 | e | ≤0.012 | ≤0.30 | ≤0.30 | 0.25to0.35 |
|
| Steel Grade | Delivery State | Thickness mm | Yield Strength Mpa≥ | Tensile Strength | Elongation %≥ | Minimum Impact Power of Temperature | | name | number | Mpa | -20 | 0 | 20 | | 16Mo3 | 1.5415 | +Ne | ≤16 | 275 | 440~590 | 22 | f | f | 31 | | 16<t≤40 | 270 | | 40<t≤60 | 260 | | 60<t≤100 | 240 | 430~560 | | 100<t≤150 | 220 | 420~570 | | 150<t≤250 | 210 | 410~570 |
|
You could also ask for other special treatment.We have a carbon
steel processing factory in Wuxi.
4. Standard:
GB,ASTM,AISI,BS,JIS,DIN,EN
5. Packing:
Standard stainless steel shipping packaging or as customer
required.
